Production Capacity: 60 m³/h
Project Location: South Korea
Main Technical Parameters: Twin-shaft forced mixer (1 m³), total power 115 KW, discharge height 3.8 m (customizable), 3 aggregate bins (1.6 m³ each), aggregate weighing accuracy ±2%, water/cement/additive weighing accuracy ±1%
Key Advantages of AGICO's Plant: Compact structure, high stability, uniform mixing, PLC automatic control, dust removal system, low consumption, cost saving
What Customers Care About Most: Reliable quality, easy installation, customized design, stable production, good after-sales service, and long service life
Project Background
A South Korean customer contacted AGICO CEMENT in 2024. He needed a concrete batching plant for his new project. After several discussions, he chose the HZS60 model. The plant is now being built in South Korea.
This customer did not want a standard machine. He asked for some changes. So AGICO designed a customized solution for him. The customer visited AGICO's factory in Henan. He talked with AGICO's engineers face to face. They discussed the layout, the capacity, and the site conditions. After the agreement was signed, AGICO started production.
AGICO sent technicians to South Korea. They went to the construction site. They helped the customer install the plant. They also trained the customer's workers. The customer was happy with AGICO's service. He said he would order two more plants later.
What the Customer Cared About Most
Before buying, the customer asked many questions. He cared about several things.
Production Capacity
Can the plant produce 60 m³/h steadily? AGICO showed him the test data. The plant meets this standard.
Concrete Quality
Will the mixer produce uniform concrete? AGICO uses a twin-shaft forced mixer. It mixes materials evenly. The quality is stable.
Installation
Is the plant easy to install? AGICO's compact design saves time. AGICO also sends technicians for guidance.
Customization
Can the plant fit his site? AGICO's engineers redesigned the layout. The plant fits his site well.
After-Sales Service
What if a problem occurs? AGICO offers a 12-month warranty. AGICO's team responds quickly.
Price
Is the investment worth it? The HZS60 plant costs $40,000 to $50,000. AGICO's plant has a long service life. It saves money in the long run.
Equipment Configuration
The HZS60 concrete batching plant has a production capacity of 60 cubic meters per hour. AGICO equips it with an efficient twin-shaft forced mixer. This mixer ensures high uniformity and quality of concrete.
The plant consists of several main parts.
Mixer: AGICO uses a twin horizontal shaft forced mixer. It can mix various types of concrete. A planetary mixer can also be configured.
Batching Machine: AGICO divides the batching machine into different silos. It stores cement, sand, aggregates, and other ingredients separately. The automated batching system ensures the accuracy of raw material dispensing.
Material Storage System: This includes cement silo, aggregate silo, and powder silo. They are used to store different raw materials.
Control System: AGICO adopts a PLC automatic control system. Users can monitor the operation status in real time. The system also supports remote operation and management.
Transportation System: This system transports raw materials to the mixer. AGICO offers two options: belt conveyor and hopper conveyor.
Dust Removal System: AGICO equips the plant with an effective dust removal system. It reduces pollution during operation.
Power Distribution System: This system provides stable power supply for the whole equipment.
| Model | HZS60 | |
|---|---|---|
| Specification | Unit | Value |
| Productivity | m³/h | 60 |
| Capacity of Mixer | m³ | 1 |
| Mixer Power | kw | 37 |
| Discharge Height | m | 3.8 (for customers choice) |
| Aggregate Bin Quantity | - | 3 |
| Aggregate Bin Capacity | m³ | 1.6 |
| Max. Weighing Value of Aggregate | kg | 3000 |
| Max. Weighing Value of Cement | kg | 600 |
| Max. Weighing Value of Water | kg | 400 |
| Max. Weighing Value of Additive | kg | 50 |
| Aggregate Measuring Accuracy | % | 2 |
| Water Measuring Accuracy | % | 1 |
| Cement Measuring Accuracy | % | 1 |
| Additive Measuring Accuracy | % | 1 |
| Control Mode | - | Auto/semi-control |
Parameters are for reference only. Please consult AGICO for details.
Investment Cost Analysis
The price of an HZS60 concrete batching plant with basic configuration is about $30,000 to $50,000. The specific price is adjusted by the following factors.
Brand and Quality: Famous brand equipment usually has a slightly higher price. But the quality and after-sales service are more guaranteed. AGICO CEMENT helps customers obtain high-quality equipment and comprehensive services.
Transportation and Installation Costs: These costs also need to be considered. Especially for cross-border transportation, the costs may increase.
Additional Configurations: Automation control systems and additional dust removal equipment will affect the final price.
The initial investment for an HZS60 concrete batching plant is generally between $30,000 and $50,000. During operation, the costs include electricity costs, labor costs, raw material procurement costs, and maintenance costs. The electricity cost depends on the frequency and scale of use. The labor cost includes the wages of operators. The purchase price of raw materials is greatly affected by market fluctuations. Maintenance costs are also required. The equipment needs to be regularly inspected and maintained. This ensures long-term stable operation.
Why Choose AGICO
Choose the plan that suits you best.
AGICO CEMENT specializes in designing concrete mixing plants. AGICO's plants offer significant cost-effectiveness advantages. AGICO provides turnkey service. The service includes demand analysis, design, agreement signing, prepayment, production, installation, and training.
This project in South Korea is a good example. The customer trusts AGICO's quality and service. AGICO is committed to helping customers start their batching plant successfully.
AGICO offers a 12-month warranty period. AGICO's team provides comprehensive pre-sales, sales, and after-sales services. AGICO can customize solutions according to customer needs.
The AGICO HZS60 concrete batching plant is a very promising investment project. It is especially suitable for areas with high demand for concrete.
